Athena Fork Oil Seal pair – 47 x 58 x 10 NOK (455076)

Athena offers the most complete range of fork oil seal kits on the market. Sourced from the world’s leading seal manufacturers, the quality of Athena oil seals meets or exceeds OEM quality. In some cases there are several different seal designs for a given size. If you can’t see your bike listed below, contact us for help – please don’t just order seals by size.

This 455076 kit is composed of two fork oil seals with exterior part in rubber, a single sealing lip and a dust seal lip:

• Internal seal / fork diameter 47 mm
• Oil seal external diameter 58 mm
• Oil seal height 10 mm
• Oil seal structure One seal lip and one dust lip

Compatible with:

• HONDA CR R 250 cc 1997/2007
• HUSQVARNA CR 250 cc 1997/1998
• KAWASAKI KX F 250 cc 2006/2012
• MARZOCCHI MAGNUM 47 MM FORK TUBES
• SUZUKI DR-Z SM 400 cc 2005/2009
• SUZUKI RM 125 cc 2001/2008
• SUZUKI RM 250 cc 2005/2008
• SUZUKI RM-Z 250 cc 2007/2012
• SUZUKI RM-Z 450 cc 2005/2009
• SUZUKI RM-Z 450 cc 2012

OEM Codes:

• HONDA 51490KZ3B01
• KAWASAKI 920490074
• SUZUKI 5115337F80
• SUZUKI 5115336F00
